Container Specifications
|
- |
INTERIOR DIMENSIONS |
DOOR OPENING |
|
L |
W |
H |
W |
H |
|
MM |
FT |
MM |
FT |
MM |
FT |
MM |
FT |
MM |
FT |
|
20' Dry Container** |
5,893 |
19' 4" |
2,337 |
7' 8" |
2,388 |
7' 10" |
2,337 |
7' 8" |
2,261 |
7' 5" |
|
40' Dry Container |
12,014 |
39' 5" |
2,337 |
7' 8" |
2,388 |
7' 10" |
2,337 |
7' 8" |
2,261 |
7' 5" |
|
40' High Cube |
12,014 |
39' 5" |
2,337 |
7' 8" |
2,667 |
8' 9" |
2,337 |
7' 8" |
2,565 |
8' 5" |
|
20' Open Top
Between top rails |
5,893
2,413 |
19' 4"
7' 11" |
2,337
2,235 |
7' 8"
7' 4" |
2,311 |
7' 7" |
2,337 |
7' 8" |
2,261 |
7' 5" |
|
40' Open Top
Between top rails |
12,014
11,506 |
39' 5"
37' 9" |
2,337
2,235 |
7' 8"
7' 4" |
2,311 |
7' 7" |
2,337 |
7' 8" |
2,261 |
7' 5" |
|
40' Refrigerated
Container |
11,557 |
37' 11" |
2,286 |
7' 6" |
2,159 |
7' 1" |
2,261 |
7' 5" |
2,159 |
7' 1" |
|
Dual Voltage: 190/230 VAC, 3-Phase, 50 Hz 380/460, 3-Phase, 60 Hz |
|
40' High-Cube Refrigerated |
11,557 |
37' 11" |
2,286 |
7' 6" |
2,466 |
8' 1" |
2,261 |
7' 5" |
2,464 |
8' 1" |
|
Dual Voltage: 190/230 VAC, 3-Phase, 50 Hz 380/460, 3-Phase, 60 Hz |
|
- |
CARGO CAPACITY |
CUBIC CAPACITY |
|
KGS |
LBS |
M3 |
FT3 |
|
20' Dry Container** |
21,800 |
48,060 |
32.9 |
1,164 |
|
40' Dry Container |
26,635 |
58,720* |
67.0 |
2,368 |
|
40' High Cube |
26,530 |
58,488* |
75.8 |
2,679 |
|
20' Open Top
Between top rails |
21,879 |
48,235* |
32.1 |
1,134 |
|
40' Open Top
Between top rails |
26,517 |
58,460* |
65.4 |
2,310 |
|
40' Refrigerated
Container |
25,760 |
56,790* |
57.2 |
2,022 |
|
Dual Voltage: 190/230 VAC, 3-Phase, 50 Hz 380/460, 3-Phase, 60 Hz |
|
40' High-Cube Refrigerated |
26,381 |
58,160* |
66.1 |
2,334 |
|
Dual Voltage: 190/230 VAC, 3-Phase, 50 Hz 380/460, 3-Phase, 60 Hz |
|
-
-
- |
DIMENSIONS |
|
L |
W |
H |
|
MM |
FT |
MM |
FT |
MM |
FT |
20' Collapsible
Flatrack |
5,867 |
19' 3" |
2,388 |
7' 10" |
2,311 |
7' 7" |
40' Collapsible
Flatrack |
12,090 |
39' 8" |
2,388 |
7' 10" |
1,979 |
6' 6" |
|
- |
CLEAR
LENGTH |
CARGO
CAPACITY |
POINT LOAD
CAPACITY |
| MM |
FT |
KGS |
LBS |
KGS |
LBS |
20' Collapsible
Flatrack |
5,613 |
18' 5" |
23,220 |
51,190 |
16,000 |
35,273 |
40' Collapsible
Flatrack |
11,751 |
38' 7" |
30,567 |
67,388* |
22,000 |
48,501 |
The general characteristics listed above are typical of units in certain series and are supplied as general information only.
AHL will be pleased to provide customers with precise information on any particular unit assigned to a shipment.
* Cargo capacity is subject to any over-the-road restrictions that might exist.
** 30 ton rated, 20 foot dry containers are available by special arrangement and on a limited basis.
|
